Many Enterprises Use Small Power 24KW 30KVA Perkins Diesel Generator with ATS

  • Description
Product Detail

    Many Enterprises Use Small Power 24KW 30KVA Perkins Diesel Generator with ATS

    This kind of Perkins Diesel Generator comes with ATS, which can automatically switch to this generator after power cutting. The diesel generator with ATS is  a good choice for you.

    Small power generators are widely used in schools, hotels and other industries, as a backup power supply or temporary power supply.


    The diesel generator with ATS

    Place of origin: Guangdong,china(Mainland)

    Brand Name: Wagna

    Model Number:DL26P-50

    Engine: 1103A-33G

    Prime power: 24KW/30KVA

    Frequency: 50HZ/60HZ


    Rated Voltage:400/230v adjustable

    Alternator:Stamford/WAGNA/Leroy Somer

    Controller: Deep Sea/Smart Gen.

    Warranty: One Year/1000 Hours


    Product parameter:

    Unit Model set





    Unit Power rate (KW)



    Engine Power rate(KVA)



    Engine Model


    Engine manufacturer

    Perkins engine

    Engine structure

    Inline 3 cylinders, four stroke, naturally aspirated

    Engine cooling mode

    40°C water tank radiator, cooling fan with fan belt drive, safety shield

    Governing system

    Electronic speed regulation control system

    Start mode

    24V DC electric start,and equipped with silicon rectifier charging generator

    Fuel System

    High pressure fuel pump

    Total engine displacement(L)




    Fuel Consumption of 100% load(g/kw·h)


    Oil Capacity (L)


    Coolant Capacity(L)


    Rated voltage / frequency /power factor

    400V/230V, 50Hz, 0.8 hysteresis, three-phase four wire

    Steady-state frequency change rate

    Better than 5%

    Insulation Class / Protection Grade

    Class H/IP 21/22/23

    Telephone influence factor /harmonic  coefficients


    Maximum noise level (dB)A


    Standard accessories

     A start battery and a connecting wire,exhaust pipe, corrugated pipe, flange, damping muffler of a base, a shock absorber

    Dimension (mm)


    Weight (kg)


    Ps. Data of above table changes sometime, for reference only.


    Product picture:

    24kw Perkins 1103A-33G.jpg

    24kw Perkins Diesel Generator.jpg

    Perkins Engine 1103A-33G.jpg

    ***Picture for guidance purpose



    1100 Series 1103A-33G

    Compression ratio. ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 19.25 : 1

    Overall dimensions

    -height... ... ... ... ... ... ... ... ... ... ... ... ... ... ... ... 951 mm (37.44 in)

    -length... ... ... ... ... ... ... ... ... ... ... ... ... ... ... .. 1029 mm (40.51 in)

    -width (including mounting brackets) ... ... ... ... 629 mm (24.76 in)

    Fuel consumption liters/hour (UK gals/hr)

    Power rating








    7,9 (1.73)

    7,1 (1.56)

    5,4 (1.18)

    3,9 (0.85)

    2,5 (0.54)


    9,5 (2.08)

    8,6 (1.89)

    6,6 (1.45)

    4,9 (1.07)

    3,1 (0.68)

    Note: All data based on operation to ISO 3046/1, BS 5514 and DIN 6271 standard reference conditions.



    Brand: Stamford

    Model :PI 144G



    Stamford industrial generators meet the requirements of

    BS EN 60034 and the relevant section of other

    international standards such as BS5000, VDE 0530,

    NEMA MG1-32, IEC34, CSA C22.2-100, AS1359/


    Control system:

    Specification of control Panel(with Deep Sea controller)

    The control panel is AMF control panel, with the display of voltage,current, frequency, water temperature, oil pressure. The genset with low oil pressure,high water temperature,over speed,over load protection function.

    The features of Deep Sea controller:

    Text based LCD display (supporting multiple languages).

    True RMS Voltage, Current and Power monitoring.

    Engine parameter monitoring.

    Fully configurable inputs for use as alarms or a range of different functions.

    Engine ECU interface to electronic engines.


    Application range:

    Perkins generator for multiple purpose of power generating solutions, including civil buildings, factories, transportation, medical, financial, telecom, military & defense, outdoor engineering,

    power generating & transportation.



    BEFORE SERVICE: According to the clients' requirement and actual situation, we will furnish the technology consultation and kinds of information.

    AFTER SERVICE: Guarantee for one year or 1000 running hours (accord to whichever reach first) from arrival date of destination port. During the guarantee period, we will provide the free easy-damaged spare-parts for problems caused by our quality of production or raw material, except the damageable spare parts of diesel engine caused by customer's incorrect man-made operation. After expiration, our company provides cost spare-parts maintenance for gensets.


    FAQ :
    Question: What's your warranty period?
    Answer: Our payment terms is 1 year or 1000 running hours whichever comes first. But based on some special project, we can extended our warranty period.

    Question: Does your generators has global warranty?
    Answer: Yes, most of our products like Cummins, Perkins, Doosan power generator enjoy the global warranty service. And the alternator we use like Leroy Somer, Stamford, marathon also enjoy the global warranty service, so you do not need to worry about the after-sales service.

    Question: What's your payment terms?
    Answer: We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight, L/C deferred payment terms or west union.

    Question: What's your delivery time?
    Answer: Delivery period normally will be 10~45 days after receiving customers' deposit.
